Ultra-bright, energy efficient, long-life Red or Green LED EXIT sign illumination
Ultra-bright, energy efficient, long-life White LED adjustable LED lamp heads provide up to 30-ft center-to-center spacing with 3-ft path of egress at 10-ft mounting height
1.5 watt (3 LEDs x 0.50 watt) per head
Unique all-inclusive lamp, reflector and lens assembly
Dual 120/277 voltage
Unique bi-color LED indicator light alerts occupant on battery condition (Green-normal, Red-check battery)
Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing
3.6V long life, maintenance-free, rechargeable NiCd battery
Internal solid-state transfer switch automatically connects the internal battery to LED board and LED lamp heads for minimum 90-minute emergency illumination
Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours
Mounting canopy included for top or end mount
Universal knockout pattern on back plate for wall mount
Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish
Snap-out Chevron directional indicators
Optional remote capacity of 2.5 watts
Optional self-diagnostic feature performs monthly, biannual, and annual tests to ensure reliable operation and meet electrical and life safety codes
Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes
UL Listed for damp locations (0°C – 50°C)
Certified to CEC under Title 20 Regulations
5-Year Warranty
Dimensions: 17"L x 2-15/16"W x 8"H
