All units come with two face plates and blank plate
Long lasting, efficient ultra bright white LED lamp heads
1 watt (8 LEDs x 0.125W) per head
High performance chrome-plated metallized reflector and plastic lens for optimal light distribution
Adjustable LED lamp heads provides optimal center-to center spacing.
Dual 120/277 voltage
Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing
9.6V Long life, maintenance-free, rechargeable NiCd battery
Internal solid-state transfer switch automatically connects the internal battery to LED board and LED lamp heads for minimum 90-minute emergency illumination
Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours
Remote capacity option available
Optional self-diagnostic feature performs monthly, biannual, and annual tests to ensure reliable operation and meet electrical and life safety codes
EZ-snap mounting canopy included for top or end mount
Universal K/O pattern on back plate for wall mount
EZ snap-out chevron directional indicators
Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes
UL Listed for damp locations (0°C – 40°C)
Certified to CEC under Title 20 Regulations
5-Year Warranty
Dimensions: 20-5/16"L x 2"W x 8"H
